272
SWITCHES
UNISWITCH ? SWITCHES – SERIES BXR PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
BOX SWITCH ? SWITCHES
BXR013PC
SHOWN ACTUAL SIZE
Rear view, BXR056
Solder Lug/Quick-Connect
Rear view, BXR013PC
PC Terminals.
SERIES BXR
Economical momentary, non-illuminated switches feature
Terminals.
PART NUMBERS
“Adjusto-Clip” snap-lock mounting and selection of switching.
Pushbutton Color/Part Number
Circuits
Bezel trims mounting and enclosed construction protects
Red
Black
Green
White
against dust, dirt, and physical damage. Color pushbuttons
have concave face for positive “feel”.
BXR011
Solder Lug/Quick-Connect Terminals
BXR021 ? BXR031 BXR051
1-A
FASTON is a registered trademark of AMP INC.
MOUNTING
Front mount in .620" (15.75 mm) minimum square hole.
Solder lug/quick-connect terminals accept AMP FASTON ?
110 terminals; PC terminals fit boards up to .281" (7.14 mm)
thick. “Adjusto-Clip” permits mounting in panels from .047 "
(1.19 mm) to .281" (7.14 mm) thick.
?
BXR013
BXR016
BXR0110
? BXR011PC
? BXR013P
BXR016PC
? BXR0110PC
BXR023
BXR026
? BXR0210
? BXR021PC
? BXR023P
BXR026PC
? BXR0210PC
BXR033
BXR036
? BXR0310
PC Terminals
? BXR031PC
? BXR033PC
? BXR036PC
? BXR0310PC
BXR053
BXR056
? BXR0510
? BXR051PC
? BXR053PC
? BXR056PC
BXR0510PC
1-C
2-C
2-A + 2-C
1-A
1-C
2-C
2-A + 2-C
SPECIFICATIONS
Housing: Molded plastic, charcoal gray only.
Pushbutton: Molded plastic; red, black, green, and
? Special order only; contact factory for price and delivery.
“ADJUSTO-CLIP” MOUNTING POSITIONS
white standard.
Position
Panel Thickness Inch (mm)
“Adjusto-Clip” Mounting Frame: Copper alloy, plated.
Contact Springs: Copper alloy, plated.
Contacts: Integral, copper alloy, plated.
1-A, 1-C, 2-C, or 2-A + 2-C
Switching: 250 mA, 30 W max., AC, non-inductive load.
Number
1*
2
3
4
5
Minimum
.047 (1.2)
.094 (2.4)
.141 (3.6)
.188 (4.8)
.234 (6.0)
Maximum
.094 (2.4)
.141 (3.6)
.188 (4.8)
.234 (6.0)
.281 (7.1)
Terminals: Copper alloy, silver-plated.
SPECIAL ORDER FEATURES
? Other contact platings.
? Engraved legends (see page 270).
? Other pushbutton colors.
? “Adjusto-Clips” set to positions 2, 3, 4, or 5.
* “Adjusto-Clips” normally installed in this position unless otherwise specified.
SCHEMATIC
RECOMMENDED
PC BOARD LAYOUT
PANEL
CUTOUT
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
